WD4-548 58 inch curved glass display case front view
Roll over image to zoom in Click on image to zoom
WD4-548 58 inch curved glass display case front view

58" Curved Glass Display Case – 16.5 Cu. Ft.

SKU: WD4-548
Price:
$1,690.90
Product Highlights
Refrigerated or Frozen Use
16.5 Cu. Ft. Display Capacity
Coated Tempered Glass Cover
5 Baskets/Shelves
Mechanical Temperature Control
Ships from LALocal stock
Lead TimeIn-stock processing
Delivery Time5–8 days
Shipping AreaLos Angeles area
Specifications

General

Model WD4-548
Overall Dimensions 58.07 × 30.12 × 32.87 in 1475 × 765 × 835 mm
Capacity 16.5 cu. ft. 468 L
Net Weight 100 kg

Refrigeration

Temperature Range 32–50°F or ≤-0.4°F 0–10°C or ≤-18°C
Cooling Type Direct cooling
Refrigerant R290

Electrical & Construction

Voltage / Frequency 115 V / 60 Hz
Power 300 W
Energy Consumption 4.16 kWh/24h

Product Configuration

Doors 2
Shelves 5 baskets/shelves

Description

Key Features

Curved Glass Cover

The coated tempered glass cover keeps products visible to customers.

5 Baskets/Shelves

Separate compartments keep different products organized inside the case.

Refrigerated or Frozen Use

Runs at 32–50°F for refrigerated display, or ≤-0.4°F for frozen display, one mode at a time. Set it with the mechanical temperature control.

Casters for Easy Placement

Comes with 2-inch casters (2 swivel, 2 locking), so the case is easier to position during installation and service.

Shipping, Returns & Warranty

Shipping & Delivery

Delivery areas, estimated transit times and receiving requirements.

View Shipping Policy →

Returns & Refunds

Return eligibility, damaged shipments, refunds and applicable conditions.

View Return & Refund Policy →

Warranty

1-Year Full Warranty and 3-Year Compressor Warranty.

View Warranty Policy →

You may also like

Recently viewed

You may also like

You may also like

Frequently Asked Questions

Quick answers to common questions about this product.

Installation & Electrical

What room temperature and humidity does this freezer require?

For reliable operation, keep the room temperature below 32°C and relative humidity (RH) below 60%.

What plug does this unit use? Does it need a dedicated circuit?

It uses a standard NEMA 5-15P plug. A dedicated circuit is not required.

Will the freezer fit through my doorway? Do I need liftgate service?

Before ordering, compare the freezer dimensions with the narrowest doorway on the delivery path. If your location does not have a forklift or other unloading equipment, select liftgate service.

Use, Glass Doors & Defrost

What can I store in this freezer?

This freezer is suitable for ice cream, frozen foods, and bagged ice.

Do the glass doors self-close? Can they stay open or be reversed?

Yes. The doors stay open at 90° and self-close when opened less than 90°. The door swing is factory-set and cannot be reversed on site.

Are the glass doors heated to help prevent condensation?

Yes. Electric glass heat and front airflow help reduce condensation. Under normal operating conditions, visible condensation should be minimal.

Does the freezer need a drain line?

No. An external drain line is not required; defrost water evaporates automatically.

Cleaning & Maintenance

How should I maintain the freezer?

Frost: Defrost regularly to prevent heavy buildup, which can reduce cooling performance and shorten door-gasket life.

Condenser: Remove dust regularly with a soft brush or vacuum. Do not spray or rinse the condenser directly with water.

Glass: Use a mild glass cleaner. Avoid ammonia, alcohol, and abrasive cleaners, which may damage the Low-E coating.

Door gaskets: Wipe with a mild detergent. Check regularly for cracks or wear, and keep the gaskets clean and flexible.
